Ink Control And The "Dynamic Balance" In Screen Printing

In screen printing, ink control is far from a simple "on/off" operation—it represents a sophisticated, continuous "dynamic balance." The core of this balance lies in coordinating the "output" of the squeegee with the "replenishment" of the flood bar. The screen printing machine acts as both the stage and the conductor of this performance, transforming the operator's expertise into stable, repeatable, and precise actions.

---

I. Core Philosophy: "Dynamic Balance"

"Dynamic Balance" refers to the process of precisely setting and adjusting the ink transfer volume (squeegee) and the ink supply volume (flood bar) during the repetitive printing cycles of the screen printing machine. This achieves a stable state best suited to the current substrate and ink characteristics. The seamless coordination of these three elements is key to obtaining an ideal ink layer with "one-time setup, consistent results."

• The Squeegee is the "Releaser": It is responsible for accurately and quantitatively transferring ink through the screen onto the substrate, forming the ink layer.

• The Flood Bar is the "Reservoir": It evenly and smoothly redistributes the ink across the screen after printing, preparing for the next cycle.

• The Screen Printing Machine is the "Coordinator": It provides a stable platform for the two blades, ensures precise parameter control, and maintains consistent cycle timing.

---

II. Achieving Balance: The "Blade Duet" on the Screen Printing Machine

The screen printing machine elevates the coordination between the squeegee and flood bar from manual experience to a quantifiable and repeatable precision operation.

1. Squeegee Angle: The "Ink Release Valve" Set on the Machine
The squeegee angle (the angle between the blade and the screen) is the primary tool for controlling ink layer thickness, and the machine's angle adjuster ensures precision.

• Large Angle (>75°): When set to a large angle, the squeegee acts like a "sharp blade," with strong shear force and less ink deposition. Suitable for:

  • Substrates: Smooth, hard surfaces (e.g., glass, metal, hard plastic).

  • Result: Thin, even, and sharp ink layers with fine details.

• Small Angle (45°–60°): When set to a small angle, the squeegee acts like a "trowel," gently pressing the ink through the mesh. Suitable for:

  • Substrates: Rough or porous surfaces (e.g., textiles, leather, paper).

  • Result: Thick, full ink layers that ensure sufficient penetration and coverage.

Value of the Machine: It allows operators to precisely set and lock the angle, ensuring this critical parameter remains unchanged over thousands of prints.

2. Flood Bar Height: The "Ink Reservoir" Adjusted on the Machine
The gap between the flood bar and the screen, controlled by the machine's precision mechanism, determines the ink volume on the screen after flooding.

• High Position: Raising the flood bar accumulates a thicker ink layer on the screen. Suitable for:

  • Requirements: Thick ink layers and high opacity.

  • Ink: High-viscosity or thixotropic inks.

• Low Position: Lowering the flood bar spreads a thinner ink layer on the screen. Suitable for:

  • Requirements: High-precision printing, preventing ink bleeding or dot gain.

  • Ink: Low-viscosity inks with good flowability.

Value of the Machine: It enables micron-level adjustments of the flood bar height and synchronizes with the squeegee system to create a "forward supply depot" for ink.

3. Pressure Synergy: The "Constant Finger Pressure" Provided by the Machine
Value of the Machine: It eliminates the instability of manual force, converting "feel" into repeatable "data."

• Squeegee Pressure: The machine (especially automatics) provides quantifiable, constant pressure via pneumatic or servo systems. The principle is to use the minimum necessary pressure to ensure complete ink transfer. Excessive pressure disrupts balance, causing dot distortion or premature screen wear.

• Flood Bar Pressure: Typically set lower than the squeegee pressure, its core function is to spread ink gently, not scrape it.

---

III. Practical Application: How the Machine Enables "Printing by Substrate"

• Printed Circuit Boards (Smooth & Hard)

  • Machine Settings: Large squeegee angle + Medium flood bar height + High squeegee pressure + Harder squeegee blade.

  • Balance Logic: The sharp angle and pressure ensure fine-line clarity, while moderate flooding maintains uninterrupted ink supply.

• Cotton T-Shirts (Soft & Porous)

  • Machine Settings: Small squeegee angle + Low flood bar height + Moderate pressure + Softer squeegee blade.

  • Balance Logic: The gentle angle promotes ink penetration; low flooding prevents surface pooling, ensuring breathable and non-cracking prints.

• Irregular Surfaces (e.g., Plastic Bottles)

  • Machine Settings: Small squeegee angle + Adaptive pressure system (if available) + Slower printing speed.

  • Balance Logic: The machine’s stability and flexible squeegee settings ensure proper contact with curved surfaces for uniform ink deposition.

---

A true master of ink control understands that the squeegee and flood bar are the "instruments" in their hands, while the high-performance screen printing machine is the "piano" on which the perfect performance is played. The philosophy of "Dynamic Balance" is ultimately realized through each precisely executed parameter on the machine.
